12 T6137pr-0920
SIDE VIEW
FRONT VIEW
ASSEMBLY
Map
Map Clip
Using safety scissors, cut the plastic tie holding Map •
in the clip.
Fit the clip to the windshield.
•
Insert a #10 x ¾" screw into the clip and tighten. •
Replace Map into the clip. •
Note to retailer: Do not remove the plastic tie. Simply
remove Map from the clip. Assemble the clip to the
windshield and replace Map in the clip.
15
16
Using safety scissors, cut the plastic tie holding •
Backpack in the holder. Remove Backpack from
the holder.
Note to retailer: Do not remove the plastic tie. Simply
lift Backpack from the holder and assemble the holder
to the top edge of the vehicle. Replace Backpack in
the holder.
Fit the holder to the top edge of the vehicle, as shown. •
Insert two #10 x ¾" screws into the holder. Tighten the •
screws.
Backpack
Backpack
Holder
