ASSEMBLED PARTS
Fasteners Shown Actual Size
For your convenience, we included an extra fastener!
Note: Tighten and loosen all screws with a Phillips
screwdriver. Do not over-tighten the screws.
12 Volt Charger
12 Volt Battery
#8 Acorn Lock Nut – 2
#10 x
3
/
4
" Screw – 18
#8 x
5
/
8
" Screw – 2
5
/
32
"x 1
1
/
2
" Pin – 1
2 Light Covers
2 Hood Latches
Key Assembly
Steering Column Cap
Steering Wheel Cap
Steering Column
Steering Wheel
Long Seat Belt Strap
2 Short Seat Belt Straps
Map Clip
Map
