29
z 1:n operation standby mode
z Mutual standby mode
z TCP/IP communication
z Using to the cluster interconnect (PRIMECLUSTER). (But, using in a JumboFrame or as
VLAN interface can not be performed)
The support ranges of takeover form are the following ranges.
a. PRIMECLUSTER
Taking over form Support
IP Support
MAC Not Supported
(Supported V4.1A10 or later)
IP+ MAC Not Supported
(Supported V4.1A10 or later)
Caution
Using over operation management LAN (LAN used for cluster operation management view) cannot be
supported.
4.5.2 Cluster Environment Setup Procedure
Set up the cluster environment in the same way as for the other LAN driver, follow "Setting up the
Network" in the "PRIMECLUSTER manual". Note that the secondary LAN port (fjgi interface) resource
name is "fjgi".
4.5.3 Notes in Cluster Environment
Please use "PRIMECLUSTER 4.1 or later" for a cluster system to use fjgi interface. If an earlier version of
cluster system is used, fjgi interface cannot be used for private LAN nor for IP address fail-over on public
LAN.
When using fjgi interface as the cluster interconnect, please perform the following command before initial
composition setup.
# ifconfig fjgi* plumb
* is instance-number
Then, please execute the following command and check that a MTU size of fjgi interface is not 9000byte
(JumboFrame is not set up).
# ifconfig fjgi*
* is instance-number
GigabitEthernet in a JumboFrame function cannot be used to the cluster interconnect.
GigabitEthernet as VLAN interface cannot be used to the cluster interconnect.
