HP StorageWorks All-in-One Storage Systems
Unified solutions combining shared iSCSI storage and customised NAS file serving with
integrated data protection, designed to be deployed and managed by IT generalists with
no storage expertise .
Entry-level
New
HP StorageWorks 400t All-in-One
Storage System (AiO400t)
HP StorageWorks 400r All-in-One
Storage System (AiO400r)
HP StorageWorks 1200r All-in-One
Storage System (AiO1200r)
HP StorageWorks All-in-One
SB600c Storage Blade (AiO SB600c)
Processor type and description
Dual-Core Intel
®
Pentium
®
E2160
1 .8 GHz with 1x1 MB L2 cache
Quad-Core Intel
®
Xeon
®
processor
E5405 (2 .00 GHz, 80W, 1333
MHz FSB) (One processor
standard; up to 2 supported)
Quad-Core AMD Opteron
TM
Model 2354 2 .2 GHz
One Quad-Core Intel
®
Xeon
®
E5410 (2 .33 GHz, 1333 FSB, 80w)
Memory standard/max
2 GB/4 GB
2 GB/4 GB
2 GB or 4 GB/4 GB
2 GB/4 GB
Storage included
4 non-Hot-Plug drives:
1 TB SATA (250 GB)
584 GB SAS (146 GB)
4 Hot-Plug drives:
1 TB SATA (250 GB)
2 TB SATA (500 GB)
1 .2 TB SAS (300 GB)
Up to 12 Hot Plug drives:
3 TB SATA (12 X 250 GB)
6 TB SATA (8 X 750 GB)
9 TB SATA (12 X 750 GB)
12 TB SATA (12 X 1 TB)
2 .4 TB SAS (8 X 300 GB)
3 .6 TB SAS (12 X 300 GB)
5 .4 TB SAS (12 X 450 GB)
292 GB 2x146 GB 10K SFF SAS
have the OS pre-installed on
the server
Choose up to 6 SFF drives:
146 GB 10K SAS SFF
250 GB 5 .4K SATA SFF
Storage controller
Smart Array E200/128 MB Controller with BBWC
Smart Array P800/512 MB
Controller (RAID 0/1/5/6) with
BBWC and 2 external SAS
expansion ports
Smart Array E200i
Network controller
Embedded NC105i PCIe Gigabit
Ethernet Server Adapter plus
additional NC360T dual-port
Gigabit Ethernet Server Adapter
Embedded NC320i PCIe Dual
Port Gigabit Server Adapter
Embedded NC326i PCIe Dual
Port Gigabit Server Adapter
Integrated single port
NC373i Multifunction Gigabit
Server Adapter
Integrated application data
storage (iSCSI SAN)
iSCSI support for Windows 2000, Windows Server 2003, Windows Server 2008 (including Hyper-V), VMware ESX Server 3/3 .5, Novell
SUSE Linux Enterprise Server 10, Red Hat Enterprise Linux 5 and Qlogic 40xx series iSCSI hardware HBAs
Integrated file serving (NAS)
Heterogeneous file serving with support for SMB/CIFS, NFS, AppleTalk, Novell, HTTP, FTP
Integrated data protection
File and array snapshots (64/volume for files and 512/volume for iSCSI) . Full copy of HP Data Protector Express software for backup and
recovery to disk or tape . Supports replication through HP StorageWorks Storage Mirroring
Operating system
Microsoft Windows Storage Server 2003 R2 (Standard Edition)
Hardware warranty
1-year parts exchange, 1-year labour, 1-year on-site next business day response
3-year parts, 3-year labour and
3-year on-site limited global warranty
QuickSpec URLs
HP related services
Recommended services
3 years Support Plus 24
Hardware Installation
HP Proactive Select Service
3 years Support Plus 24
Hardware Installation
HP Proactive Select Service
3 years Support Plus 24
Hardware Installation
HP Proactive Select Service
3 years Support Plus 24
Installation and Startup Service
for HP BladeSystem c-Class
Infrastructure (OS + ICE)
HP Proactive Select Service
Software
HP StorageWorks Storage Mirroring to replicate iSCSI array and file data to another system
HP StorageWorks Data Protector Express Options to protect servers connected to the AiO
Tape
SAS Ultrium tape drives
USB, SCSI and SAS DAT
tape drives
SCSI Ultrium tape drives
1/8 G2 Autoloader with
Ultrium 448/920 Tape Drive(s)
1/8 G2 Autoloader with
Ultrium 920/1760 Tape Drive(s)
MSL2024 Tape Library with Ultrium
920/960/1760 Tape Drive(s)
MSL2024 tape library with 920
SAS or Ultrium 960 4Gb Fibre
MSL4048 tape library with 920
SAS or Ultrium 960 4Gb Fibre
For more information, visit: www.hp.com/go/AiOStorage
