Power Jet-Light 3 x 36 W IP 54
Operating Manual 16 GB
Pos. Name Pos. Name
12 Shockproof sockets 14 Bush including bending protection
13 Casing 15 Switch ON / OFF
5 Technical Data
Device Power Jet - Light 3 x 36 W
Type Nr. 1 17261 0
Protection type: IP 54 (splash water protected, dust protected)
Power consumption: 230 V~ 50 Hz
Cable: Rubber cable H07RN-F 3G1,5
Cable length: around 5 m
Dimensions (H x B x T): around 555 x 415 x 235 mm
Weight: 6.3 kg
Lamp:
Power consumption:
up to 3 x 36 W (Illuminant)
Illuminant: 3 x 36 W, PL Compact lamp
Protection class: II
Multiple socket inserts:
Protection class:
I
Max. Load: max. 3500 W
Rating current: max. 16 A
6 Operation and Installation
Please observe the following notes, especially the security notes in order to avoid faulty operations and
possible defects.
12
13 15
14
