Picture to be added. picture to be added – Lingenfelter L820xxxxxx Lingenfelter Cadillac CTS Billet Pedal v1.1 User Manual
Page 3
Page 2.
Tools & Materials Required
• Drill
• 1/8” drill bit
• 3/16” drill bit
• Phillips screwdriver or drill bit
• 9mm wrench
• Safety glasses
• Flashlight
• Vacuum
• 3/32” Allen key (included)
• Center punch
• Silver marker
2008-2012 CTS AT
L820130709
2008-2012 CTS MT
L820120709
2008-2012 CTS MT Wide
Pedal L820110709
2004-2007 CTS MT Wide
pedal L820090704
2004-2007 CTS MT Standard
pedal L820100704
2004-2007 CTS Pedal cover kit MT Standard Gas Pedal L820100704
#
Description
1
Standard gas pedal cover
1
Brake pedal cover
1
Clutch pedal cover
1
Parking brake cover
1
Foot rest cover
8
8 x 1/2” self tapping countersink screws
8
8-32 lock nuts
8
8-32 x 3/4” bolts
Picture to be
added.
Picture to be
added.
