DS4830 User’s Guide

95

11.2

– I2C Slave Controller Register Description

Following are the registers that are used to control the I

2

C Slave Interface, which is the SDA and SCL pins. These

registers are used to control the I

2

C slave interface if it is operating as either a slave or master. The bit descriptions below

detail how to use these registers when operating in slave mode. When operating in master mode, some of the bits and
registers have different functionality. See the I

2

C Master Interface for more information on how to control the I

2

C Slave

Interface when it is operating as a master.

11.2.1

I

2

C Slave Control Register (I2CCN_S)

Address: M2[0Ch]

Bit

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

0

Name

-

-

-

-

-

SMB_MOD I2CSTREN I2CGCEN

I2CSTOP

I2CSTART

I2CACK

I2CSTRS

-

-

I2CMST

I2CEN

Reset

0

0

0

0

0

0

0

0

0

0

0

0

0

0

0

1

Access

r

r

r

r

r

r

rw*

rw*

r

r

rw*

rw*

r

r

r

rw*

* Unrestricted Read. Unrestricted write access when I2CBUSY=0. Writes to I2CEN are disabled when I2CBUSY=1.


BIT

NAME

DESCRIPTION

15:11

Reserved

Reserved. The user should write 0 to these bits.

10

SMB_MOD

Slave SMBUS Mode Operation. When this bit is set to a

‘1’, SMBus timeout functionality is enabled for the

I

2

C slave interface.

When this bit is cleared to ‘0’, the SMBus timeout functionality is disabled. See the

SMBus Timeout section for more details.

9

I2CSTREN

I

2

C Slave Clock Stretch Enable. Setting this bit to '1' will stretch the clock (holds SCL low) at the end of the

clock cycle specified in I2CSTRS. Clearing this bit disables clock stretching.

8

I2CGCEN

I

2

C Slave General Call Enable. Setting this bit to '1' will enable the I

2

C to respond to a general call address

(address = 0000 0000). Clearing this bit to '0' will disable response to general call address.

7

I2CSTOP

This bit has no function when operating in slave mode.

6

I2CSTART

This bit has no function when operating in slave mode.

5

I2CACK

I

2

C Slave Data Acknowledge Bit. This bit selects the acknowledge bit returned by the I

2

C controller while

acting as a receiver. Setting this bit to ‘1’ will generate a NACK (leaving SDA high). Clearing the I2CACK bit
to ‘0’ will generate an ACK (pulling SDA LOW) during the acknowledgement cycle. This bit will retain its
value unless changed by software or hardware.

4

I2CSTRS

I

2

C Slave Clock Stretch Select.

Setting this bit to ‘1’ will enable clock stretching after the falling edge of the

8

th

clock cycle. Clearing this bit to ‘0’ will enable clock stretching after the falling edge of the 9

th

clock cycle.

This bit has no effect when clock stretching is disabled (I2CSTREN=0).

3:2

Reserved

Reserved. The user should write 0 to these bits.

1

I2CMST

I

2

C Master Mode Enable.

Setting this bit to ‘1’ will enable I

2

C master functionality on the SDA and SCL

pins. See the I

2

C

Master Interface section for more details. Setting this bit to ‘0’ enables I

2

C slave

functionality.

0

I2CEN

I

2

C Slave Enable. This bit enables the I

2

C Slave function. When set to

’1’, I

2

C Slave communication is

enabled. When cleared to

‘0’, the I

2

C function is disabled.
