DS4830 User’s Guide

219

XOR src

Logical XOR


Description:

Performs a logical-XOR between the active accumulator (Acc or A[AP]) and the specified src
data. For the complete list of src specifiers, reference the MOVE instruction. Because the source
is limited to 8 bits, the PFX[n] register is used to supply the high-byte of data for 16 bit sources.

Status Flags:

S, Z


Operation:

Acc  Acc XOR src


Encoding:

15

0

f011

1010

ssss

ssss


Example(s):

; Acc = 2345h

XOR A[2]

; A[2]=0F0Fh; Acc  2C4Ah


Special Notes:

The active accumulator (Acc) is not allowed as the src for this operation.



XOR Acc. Logical XOR Carry Flag with Accumulator bit


Description:

Performs a logical-XOR between the Carry (C) status flag and a specified bit of the active
accumulator (Acc.) and returns the result to the Carry.

Status Flags:

C


Operation:

C  C XOR Acc.


Encoding:

15

0

1011

1010

bbbb

1010


Example(s):

; Acc = 2345h, C=1 at start

XOR Acc.1

; Acc.1=0  C=1

XOR Acc.2

; Acc.2=1  C=0
