NX-1710E Single Door Control

12

Segment 4

LED1 (Green) Options:

LED1 -

"On" to follow Ready status of system. (Default is “On”)

LED2 -

"On" to toggle with the relay activation. (Default is “On”)

LED3 -

"On" if inverted.

LED4–8

Reserved.


Segment 5

LED2 (Red) Options:

LED1 -

"On" to follow Armed status of system. (Default is “On”)

LED2 -

"On" to toggle with the relay activation.

LED3 -

"On" if inverted.

LED4–8

Reserved.

Segments 6 – 8 Reserved

L

OCATION

1 R

EADER

“B” S

CAN

F

UNCTIONS

& O

PTIONS

(8 segments of binary data) Location 1 is used to select the particular function(s) that are activated when a card
is scanned at Reader “B”. More than one function may be selected. If more than one function is selected, they
will execute in order from function 1 to function 8.

Functions 1-6 will be performed based on the user’s authority as programmed by the [ ] [6]

function (refer to keypad user manual).

Segment 1

Single Scan Function

Program the functions that are performed when a card is scanned {one beep}.

LED1 -

"On" to send Code Entry function to the control panel.

LED2 -

"On" to activate the Armed Away mode.

LED3 -

"On" to activate the Armed Stay mode.

LED4 -

"On" to send the Disarm function to the control panel.

LED5 -

"On" to send Auxiliary Function #1 to the control panel.

LED6 -

"On" to send Auxiliary Function #2 to the control panel.

LED7 -

"On" to broadcast an X-10 function (see Location 241 for programming).

LED8 -

"On" to send a Request-to-Exit (RTE); and to activate the onboard relay. (Default
is “On”)

Segment 2

Triple Scan Function

Program the functions that are performed when a card is scanned three times {three beeps}. The descriptions
of the options are the same as for Single Scan Function (Segment 1 above). Default is 1.

Segment 3

Reader Options:

LED1 -

"On" if tamper is inverted.

LED2 -

"On" if tamper is enabled.

LED3 -

"On" if reader buzzer is to follow typical keypad buzzing.

LED4 -

"On" if reader automatically issues a beep when the card is scanned. Enabling
this option prevents the door control from issuing another beep. (Default is “On”)

LED5 -

“On” if LEDs to extinguish after 2 minutes without a scan.

(Note: This option doesn’t

disable the flashing green LED during card programming.)

LED6–8

Reserved.

Segment 4

LED1 (Green) Options:

LED1 -

"On" to follow Ready status of system. (Default is “On”)

LED2 -

"On" to toggle with the relay activation. (Default is “On”)

LED3 -

"On" if inverted.

LED4–8

Reserved.
