NX-1710E Addendum
(February 9, 2005 -- cksum 9B12)
Only the modified locations are reflected in this Addendum.
The NX-1710E has been upgraded to operate with the following 2-wire Wiegand bus interface. Readers must be able to “speak” Wiegand. The following are supported
Weigand formats by default:
•
26-bit standard Weigand
•
27-bit Tecom ASC
•
35-bit HID Corporate 1000
•
37-bit HID 10304
•
40-bit with facility code (Casi Rusco 4001)
•
40-bit without facility code (Casi Rusco 4002)
L OCATION 1 R EADER “B” S CAN F UNCTIONS & O PTIONS
Segment 3 Reader Options:
LED5 = “On” if LED to extinguish after 2 minutes without a scan. (Note: This option doesn’t disable the flashing green LED during card programming.)
L OCATION 3 P ROGRAMMING THE O PTIONS AND D OOR C ONTROL P ARTITIONS
Segment 2 Door Options
LED8 = “On” if relay operates normally during off-schedule (outside regular operating hours).
Segment 5 Weigand Format Enables:
LED1 - "On" if Weigand Format #1 is enabled. (Default is “On”)
LED2 - "On" if Weigand Format #2 is enabled. (Default is “On”)
LED3 - "On" if Weigand Format #3 is enabled. (Default is “On”)
LED4 - "On" if Weigand Format #4 is enabled. (Default is “On”)
LED5 - "On" if Weigand Format #5 is enabled. (Default is “On”)
LED6 - "On" if Weigand Format #6 is enabled.
LED7 - "On" if Weigand Format #7 is enabled.
LED8 - "On" if Weigand Format #8 is enabled.
L
OCATION 44 C ODE E NTRY L OGGING P ARTITION
(2 segments of numerical data) This location programs the partition that is logged with the Code Entry message and sent when the following conditions are met:
An RTE scan function is selected (Location 0, Segment 1/2, Option 8); and
“RTE from a scanned card is to be logged as Code Entry” is enabled (Location 3, Segment 1, Option 5).
Entering a 0 (zero) will send the lowest valid partition of the reader. Entering 1-16 will send the entered value as the partition. (Default is 0.)
Segment 1 Code Entry Logging Partition for Reader “A”
Segment 2 Code Entry Logging Partition for Reader “B”
USER-DEFINABLE FORMATS
The following locations are considered to be advanced programming and should ONLY be used by installers with a thorough
understanding of Weigand Formats. Do not attempt to program these locations if you are not familiar with Weigand packets.
L
OCATION 45 WEIGAND FORMAT 1 (S TANDARD 26 BIT ) – D IGITS & B ITS
(5 segments of decimal data) This is the first location used to program the Weigand Format 1. (Loc 45-57)
Segment 1 Number of digits in Facility Code
Segment 2 Number of digits in Badge Number
Segment 3 Number of bits in Facility Code
Segment 4 Number of bits in Badge Number
Segment 5 Total number of bits in complete format (including parity bits)
L OCATION 46 WEIGAND FORMAT 1 – B IT D ESCRIPTORS (B ITS 1-32)
(32 segments of hex data) This location contains the descriptors for bits 1 – 32 of Weigand Format 1. The available options are: 0=Always Zero; 1=Always One; B=Badge
number; D=Parity bit; E=End of format; F=Facility Code bit. Segment 1 = Bit Descriptor 1; Segment 32 = Bit Descriptor 32.
L OCATION 47 WEIGAND FORMAT 1 – B IT D ESCRIPTORS (B ITS 33-64)
(32 segments of hex data) This location contains the descriptors for bits 33 – 64 of Weigand Format 1. The available options are: 0=Always Zero; 1=Always One; B=Badge
number; D=Parity bit; E=End of format; F=Facility Code bit. Segment 1 = Bit Descriptor 33; Segment 32 = Bit Descriptor 64.
L OCATION 48 WEIGAND FORMAT 1 – P ARITY T YPE 1
(1 segment of decimal data) This location programs the Partity Type 1 for Weigand Format 1. Available options for this location are 0 = No Parity; 1 = Odd Parity; 2 = Even Parity.
Factory default is 1.
L
OCATION 49 WEIGAND FORMAT 1 – P ARITY M ASK 1
(8 segments of binary data) This location tells which bits to include for the parity count; and includes the parity bits. It is used in conjunction with Location 48 (Parity Type 1). The factory
default is:
Seg 1 Seg 2 Seg 3 Seg 4 Seg 5 Seg 6 Seg 7 Seg 8
12345678 12345678 12345678 ------78 -------- -------- -------- --------
L OCATION 50 WEIGAND FORMAT 1 – P ARITY T YPE 2
(1 segment of decimal data) This location programs the Partity Type 2 for Weigand Format 1. Available options for this location are 0 = No Parity; 1 = Odd Parity; 2 = Even Parity.
Factory default is 2.
L
OCATION 51 WEIGAND FORMAT 1 – P ARITY M ASK 2
(8 segments of binary data) This location tells which bits to include for the parity count; and includes the parity bits. It is used in conjunction with Location 50 (Parity Type 2). The factory
default is:
Seg 1 Seg 2 Seg 3 Seg 4 Seg 5 Seg 6 Seg 7 Seg 8
12345678 ---45678 -------- -------- -------- -------- -------- --------
L
OCATION 52 WEIGAND FORMAT 1 – P ARITY T YPE 3
(1 segment of decimal data) This location programs the Partity Type 3 for Weigand Format 1. Available options for this location are 0 = No Parity; 1 = Odd Parity; 2 = Even Parity.
Factory default is 0.
L
OCATION 53 WEIGAND FORMAT 1 – P ARITY M ASK 3
(8 segments of binary data) This location tells which bits to include for the parity count; and includes the parity bits. It is used in conjunction with Location 52 (Parity Type 3). The factory
default is:
Seg 1 Seg 2 Seg 3 Seg 4 Seg 5 Seg 6 Seg 7 Seg 8
-------- -------- -------- -------- -------- -------- -------- --------
