Pressing the ESC Key or Scan/Hold Key terminates the function. Once the test is terminated, the current outputs
return to automatic control.

Caution: Manually activating current output can cause damage if control equipment is connected. Disconnect
control equipment before proceeding.

46 AutoAssign

Automatically assigns one 4-20mA per active channel.

47 defAult

Unassigns all 4-20mA channels.

48 i-AdJust

This menu is used to manually assign counts-to-milliamps outputs for 0 mA, 4 mA, and 20 mA outputs to
calibrate to another device. Follow this procedure:

1. Put the UltraWave Series in the Manual Mode. Proceed to the Main Menu/Service Menu/4/20 Menu/adj

Menu. The display shows:

Chan: 1 (Up/Down)

Enter To Select

2. Up arrow scrolls the display forward through all the current channels. Down arrow scrolls the display

backward through all the current channels. Scroll to the desired current channel.

3. Press the Enter Key to access Select. The display shows:

Select Cal Point

0mA

4. Press an arrow key to assign counts to the associated current output. If you select 0 mA, the display

looks like this:

0mA Cal Point

> x cnt

5. Use the keypad or the Up and Down Arrow Keys to change the counts if desired. Press the Enter Key to

save the value in memory. The display flashes a message acknowledging your selection and returns to:

Select Cal Point

0mA

6. If desired, repeat Steps 4 and 5 for the other current output, and repeat Steps 2 through 5 for other

current channels.

Note: If you have set up 4-20 mA output, the UltraWave Series controller ignores anything you enter for 0 mA.
Similarly, if you set up 0-20 mA output, the controller ignores anything you enter for 4 mA.
