14. For Auto and Manual calibration, the display shows:
Maximum Head Hgt
> .0 in
Use the keypad or the up/down arrow keys to enter the Maximum Head Height, obtained from the flow
chart supplied by the primary element manufacturer. Press ENTER.
15. Physically measure the Current Head. Use the keypad or the up/down arrow keys to enter the Current
Head. Press ENTER.
Current Head?
> .0 in
16. The Zero Distance shown on the display is a calculated value, for information only, and cannot be
modified while in the Auto calibration. In Manual Calibration the zero distance number must be entered.
Zero Distance = Current Head + Distance measured by transducer from face of transducer to liquid
surface. Press Enter.
Warning: Zero Distance error. Possible overflow reading change distance.
Zero Distance:
> .X in
17. Using the keypad, enter Low Head Cutoff and press ENTER.
Low Head Cutoff
> .X in
18. Press ESC to enter the values to memory.
01 FLOW
esc to exit
19. The display then shows:
Call more chans?
* No
20. Select NO to exit out of the quick configuration, skipping the setup of any remaining channels; select YES
to continue the configuration process on the remaining sensors. Once complete, the display will show:
01 FLOW
Flow: .00 CFS
