Inovonics FA104 User Manual
Page 17
© 1994 INOVONICS Corporation
13
LIT-FA104-USER 14-Nov-95
Default FA464 Transmitter Parameters
Point# Contact Output
Check-In
1
N/O
1
60
SEC
2
N/O
2
60
SEC
3
N/C
3
60
SEC
4
N/C
4
60
SEC
5
N/O
1
60
SEC
6
N/O
2
60
SEC
7
N/O
3
60
SEC
8
N/O
4
60
SEC
9
N/C
1
60
SEC
10
N/C
2
60
SEC
11
N/C
3
60
SEC
12
N/C
4
60
SEC
13
N/C
1
60
SEC
14
N/C
2
60
SEC
15
N/C
3
60
SEC
16*
N/C
4
NONE
17
N/C
5
60
SEC
18
N/C
5
60
SEC
19
N/C
5
60
SEC
20
N/C
5
60
SEC
21
N/C
6
60
SEC
22
N/C
6
60
SEC
23
N/C
6
60
SEC
24
N/C
6
60
SEC
25
N/C
7
60
SEC
26
N/C
7
60
SEC
27
N/C
7
60
SEC
28
N/C
7
60
SEC
29
N/C
8
60
SEC
30
N/C
8
60
SEC
31
N/C
8
60
SEC
32 N/C 8
60
SEC
Point# Contact Output
Check-In
33
N/C
9
60
SEC
34
N/C
9
60
SEC
35
N/C
9
60
SEC
36
N/C
9
60
SEC
37
N/C
10
60
SEC
38
N/C
10
60
SEC
39
N/C
10
60
SEC
40
N/O
10
60
SEC
41
N/O
11
60
SEC
42
N/O
11
60
SEC
43
N/O
11
60
SEC
44
N/O
11
60
SEC
45
N/O
12
60
SEC
46
N/O
12
60
SEC
47
N/O
12
60
SEC
48
N/O
12
60
SEC
49
**
N/O 13
5
MIN
50
N/O
13
5
MIN
51
N/O
13
5
MIN
52
N/O
13
5
MIN
53
N/O
14
5
MIN
54
N/O
14
5
MIN
55
N/O
14
5
MIN
56
N/O
14
5
MIN
57
N/O
15
5
MIN
58
N/O
15
5
MIN
59
N/O
15
5
MIN
60
N/O
15
5
MIN
61
***
N/O+INT 16
60 SEC
62
N/O+INT
16
60
SEC
63
N/O+INT
16
60
SEC
64
N/O+INT
16
60
SEC
*Note: Point 16 in Table 1 is programmed with no check-in. This configuration is often desirable for use with the FA204
Pendant, permitting the pendant to be taken out of range without being reported Inactive.
**Note: Points 49-60 are programmed to check in every five minutes.This will extend battery life slightly depending on
which transmitter is used.
***Note: Points 61 through 64: Normally Open plus Internal Contact = Yes.
