Inovonics FA104 User Manual

Page 10

LIT-FA104-USER 14-Nov-95

Programming FA416, FA416D and FA464 Receivers

Press

ENTER to program a point or to modify settings.

Press

to go to DELETE POINTS menu option or

to go to OUTPUT SETUP.

Enter point number from keypad. Press ENTER.

(Note: nn=16 or nn=64, depending on receiver.)

Is the external transmitter switch loop Normally Open or Closed?
Arrow keys toggle between N/O and N/C.

Is a 2.2K end of line resistor being used?
Arrow keys toggle between YES and NO.

Is the FA200W widegap magnet contact being used?

Arrow keys toggle between YES and NO.

How often should transmitters send supervisory data?
Arrow keys toggle between UNSUPERVISED,
10, 30, or 60 SECONDS and 5, 30 or 60 MINUTES.

Which output should this point activate?
Arrow keys select desired output.

If the selected output has been previously assigned as a global fault output, the programmer will prompt for
confirmation:

It is recommended that the output be redefined as an alarm, or
that the point be assigned to another output. Arrow keys toggle
between YES and NO.

Press ENTER to proceed with transmitter programming.
or press A to go through transmitter options again.

Connect transmitter and press transmitter reset to program device, or press
A to save program information, activate the point and select a new point
number, or press EXIT to save program information without activating the
point. One of the following displays will appear:

If a transmitter is connected, display indicates successful transmitter
programming sequence. Display remains for about 3 seconds, then
returns to the point number selection screen.

If special key A is pressed, the point is saved and activated, even
though no transmitter has been programmed. This may be
necessary when replacing receivers or when using the FA100.

If EXIT is pressed, point program information is saved without
activating the point.

POINT NUMBER:

ENTER #(1 to nn)

CHECK-IN TIME

60 SECONDS

OUTPUT TO USE:

OUTPUT 1

OUTPUT n GLOBAL

CONFIRM?

YES

USE INTERNAL

CONTACT:

END OF LINE

RESISTOR:

EXT SWITCH TYPE

NORM/OPEN

Press ENTER to

PROGRAM POINT

Program

Points

ENTER TO PROGRAM

"A" to REVIEW

CONNECT TX+RESET

OR PRESS "A"

POINT NUMBER nn

TX PROGRAMMED

POINT NUMBER nn

POINT ACTIVATED

POINT NUMBER nn

PROGRAM SAVED
