3.2 CONFIGURE PAGE PRINTER
Activate the CONFIGURE menu and press the ENTER key when the DT210 displays 'CONFIG
PAGE'.
The DT210 prompts:
"HEADER 1"
"HEADER 2"
"HEADER 3"
Enter up to 16 characters for each header label or press CONTINUE to skip a header label. The
header labels are used for print a fixed labels on the ticket such as the company name and
address, station id, etc.
The DT210 prompts with the following menu:
CONFIG PAGE 1
CONFIG PAGE 2
CONFIG PAGE 3
Press the CONTINUE key to scan the page menu.
Press the ENTER key to begin a page data entry.
Each page may have up to 25 items printed on it. The pages are organized as follows:
LINE_NO
COLUMN
ITEM
_
NO
SIZE
line_no = line number to print item on.
column = column number to begin printing item.
item_no = item to be printed ( see item list ).
size = print size: 0 = no change, 1 = small,
2 = enhance, 3 = mixed
NOTE: When the IDS 150 Printer is used, the maximum number of characters that can be
printed on one line is 40 in normal size print or 20 in enhanced mode.
