Media Gateway Configuration Examples
Only a PRI Module
This example Mediant has only a single PRI module installed.
Trunk Groups
Group
Index
Module
From
Trunk
To
Trunk Channels Phone Number
Trunk
Group ID
1
Module 1 PRI
1
1
1-23
1000
1
Tel to IP Routing
Dest Phone Prefix
Source Phone Prefix
->
Dest IP Address
1 *
*
The “Dest IP Address” above is the IP Address of the NET SatisFAXtion Fax Server.
IP to Trunk Group Routing
Dest Phone Prefix
Source Phone
Prefix
Source IP Address
->
Trunk Group ID
1 *
*
*
1
Only FXO Modules
This example Mediant has three FXO modules installed for a total of twelve FXO ports.
Trunk Groups
Group
Index
Module
From
Trunk
To
Trunk Channels Phone Number
Trunk
Group ID
1
Module 1 FXO
1-4
1000
1
2
Module 2 FXO
1-4
2000
1
3
Module 3 FXO
1-4
3000
1
Tel to IP Routing
Dest Phone Prefix
Source Phone Prefix
->
Dest IP Address
1 *
*
The “Dest IP Address” above is the IP Address of the NET SatisFAXtion Fax Server.
IP to Trunk Group Routing
Dest Phone Prefix
Source Phone
Prefix
Source IP Address
->
Trunk Group ID
1 *
*
*
1
