ASSEM BLY

3. Position speed selector lever as

sembly as shown in Figure 11.

4. Reinstall bolt, spring, washer and

locknut See Figure 12,

5. Tighten locknut until 1/8 to 3/16 inch

of the bolt threads protrude pas the
locknut.

6. Thread the 3/8-16" hex jam nut

onto the lever until the nut reaches
the end of the thread. See

Figure 12.

7. Thread the plastic knob as far as

possible and ensure that the knob
points forward.

8. Tighten the 3/8-16" hex jam nut

against the knob securely.

9. Move shifter through all speeds to

ensure proper tension of the spring.
If shifter lever sticks in any of the
notches, loosen locknut 1/2 turn at a
time until shifter lever moves more
freely.

10. If adjustment of speed of snow

blower is needed, refer to "Friction

Wheel Adjustment” in the ADJUST-

MENT/REPAIR section.

Shift Bracket

Control

Panel

Figure 11

F-001060J
