SCHEMATIC
TRACTOR - - MODEL NUMBER 917.258692
IGNtTiON SWITCH
POSITION CIRCUIT “MAKE”
I
OFF Q + M + L no S' e
RltN/UOMT B + L AtY
RUN B L NOM^
START L + S MOPE
I
MOTE
YOUR TRACTOR !S
EQUIPPED WITH A SPECIAL
alternator system ^
THE LISHTS ARE NOT
CONNECTED TO THE
BATTERY, BUT HAVE THEIR
OWN ELECTRICAL SOURCE
BECAUSE OF THIS, THE
BRIGHTNESS OF THE LIGHTS
WILL CHANGE WITH ENGINE
SPEED.' AT IDLE THE LIGHTS
WILL DIM. AS THE ENGINE IS
SPEEDED UP, THE LIGHTS
WILL BECOME THEIR BRIGHTEST.
I WIRING INSULATED CLIPS
NOTE: IF WIRING INSULATED
GUPS WERE REMOVED FOR
SERVICING OF UNIT, THEY
SHOULD BE REPLACED TO
I PROPERLY SECURE YOUR WIRING
HEADLIGHTS
RELAY
PTO SWITCH
POSSTIOH I CinCVIT
OFF . j c+s, a+H
ON ic + F. 2 + £. A -f- D
NON’REMOVABLE
CONNECTIONS
REMOVABLE
CONNECTIONS
31
