2-46
FAX-L1000 Chapter 2: Operating Instructions
#4B NCU * 1
TONE/PULSE
(NCU settings) DIAL TONE
2nd DIAL TONE
BUSY TONE 0
BUSY TONE 1
REORDER TONE
MULTI
AUTO RX
CNG DETECT
RKEY
PBX DIAL TONE
PBX BUSY TONE
SW01 SW01 to 30: Not used
SW30
#4A SPECIAL
#4C ISDN * 2
Bit 7 6 5 4 3 2 1 0
SW01
SW02
SW03
SW04
SW05
SW06
SW07
SW08
SW13
SW30
– – 1 0 – – – –
– – – – 0 0 1 –
– 1 1 0 0 0 – 0
Not used
Not used
0
0 – – – – – 0
– – – 0 – – – –
0 0 0 1 – 1 – –
– 0 0 0 – 0 0 0
(ISDN settings)
ISDN BASIC Bitswitch
SW09 to 12: Not used
SW14 to 30: Not used
01 :
16 : 0
17 :
18 : 3
19 : 3
30 :
Numeric
items 01 to 15 : Not used
Not used
items 20 to 30 : Not used
01 : 1017
128 : 0
Redial Code
G4/G3 Fallback
See Chapter 5, 3.6.3 Technical
information, d) SSSW default setting
01 : 1001
128 : 0
See Chapter 5, 3.6.3 Technical
information, d) SSSW default setting
* 1 If you install either the
optional FAX-L1000 ISDN Kit,
this function will not work.
* 2 Indicated only when the
optional FAX-L1000 ISDN Kit
is installed.
Figure 2-39 Service Data (4/6)
