Bio-Rad BioFrac™ Fraction Collector - Manual (Page 56)

4 | The User Interface
48 | BioFrac Fraction Collector
Method Library Screen
The Method Library screen is used to retrieve, save, or delete user-defined
collection methods (see Figure 19 and Table 13 ). Up to 20 methods may be stored.
Function keys are used to load, save, and delete methods or to get to the
Calibration screen (see Calibration Screen on page 49 ).
Fig. 19. Method Library screen.
The Method Library displays the Default and user-defined methods.
Table 13. Method Library screen function keys
Function Key Function
Done Returns the display to the Main screen.
Calib Displays the Calibration screen (see
Calibration Screen on page 49 ).
Load Loads the method pointed to by the cursor.
Save Allows the current fraction collection
parameters to be saved as a method. A method
name can be up to 16 characters long.
Delete Deletes the method pointed to by the cursor.
