OPERATOR’S MANUAL
AI-120 Virtual Terminal
11001-1606B-201310
58 / TERMINAL SETUP
Figure 88
Virtual Terminal Setup Menu
UNIVERSAL TERMINAL NUMBER
A universal terminal (UT) number should be assigned if there are multiple
terminals connected to the Isobus. Assigning a unique number to the
primary UT avoids communication conflicts. The UT with number 1 will be
the default terminal connected to the working set master. If the UT client
doesn’t appear on the correct UT, reconfigure the UT number appropriately.
If there is a conflict, the following message will appear:
– The UT Number of this UT conflicts with another UT on the bus,
and this UT has been disabled. Please make sure that this UT has
a unique UT Number.
Setting the Univeral Terminal Number:
1. At the Virtual Terminal Setup menu, press the UT Number button to
display the menu selections.
2. Enter a unique UT number connected to the WSMT.
Figure 89
Universal Terminal Number
