Rev 10.0/6-12 1 P1-AC: #35110
SPECIFICATIONS
Description: Designed for use with a crane or other hoisting equipment, P1-04AC lifters employ vacuum
to hold a load for lifting, and they provide manual 180° rotation and manual 90° tilt
movements for load manipulation.
Model Number: P11004AC P1HV1104AC P11104AC
Vacuum Pads: 1 (Four, standard rubber, with #60 filter screen)
10" [25 cm] nom. diameter,
concave (Model G0750)
10" [25 cm] nom. diameter,
lipped (Model HV11)
11" [28 cm] nom. diameter,
lipped (Model G3370)
Maximum Pad Spread: 49" x 10" 50" x 11" 51" x 12"
(to outer edges) [1245 mm x 254 mm] [1270 mm x 280 mm] [1295 mm x 305 mm]
Load Capacity: (rated at 16" Hg [-54 kPa] on clean, smooth, nonporous flat surfaces 2 )
Per-Pad: 150 lbs [68 kg] 150 lbs [68 kg] 175 lbs [80 kg]
Maximum: 600 lbs [270 kg] 600 lbs [270 kg] 700 lbs [320 kg]
Lifter Weight: 70 lbs [32 kg] 79 lbs [36 kg] 75 lbs [34 kg]
Power Source: See serial number plate for specific AC voltage, frequency and amperage.
Rotation Capability: Manual, 180°, with automatic locking at each ¼ revolution (when desired)
Tilt Capability: Manual, 90°, with automatic locking in vertical position
Vacuum Pump: Rotary Vane Type, 2.5 SCFM [71 liters/minute] nominal airflow
Vacuum Reserve Tank: Vacuum reservoir helps prevent immediate vacuum loss in case of power failure.
Vacuum Gauge: Dial gauge indicates current vacuum level in positive inches of Hg and negative kPa.
Low Vacuum Warning Light: Red light is energized until vacuum level is sufficient to lift maximum load weight
(higher than 16" Hg [-54 kPa]).
Options: See separate instructions about optional features.
Operating Elevation: Maximum = 8000 feet [2438 meters]
Operating Temperatures: 32° to 104° F [0° to 40° C]
Service Life: This lifter is designed to have a service life of at least 20,000 lifting cycles, when
used and maintained as intended. Vacuum pads, filter elements and other wear-out
items are excluded; see MAINTENANCE and REPLACEMENT PARTS LIST for more
information. For the D ISPOSAL OF THE L IFTER after its service life, see INTENDED USE.
ASME Standard BTH-1: Design Category "B", Service Class "0" (see www.powrgrip.com for more
information)
Wiring Diagram: The following wiring diagram is attached for reference in servicing the lifter or
trouble-shooting a deficiency: SO219059-W01 [W01]
!!-CE-!! Note: This symbol appears in the INSTRUCTIONS manual only when requirements of a CE Standard are
different from requirements of other standards that also apply to this vacuum lifter. CE requirements are mandatory
in geographical areas where CE Standards apply, but may be optional in other locations.
1
Available with optional closed-cell foam rings for rough or textured surfaces (Model P1HV11F04ACO), as well as low-marking
rubber for materials susceptible to marking (see REPLACEMENTS PARTS LIST).
2
Load Capacity is based on a friction coefficient of 1; see MAINTENANCE: V ACUUM P AD M AINTENANCE : Friction Coefficient for
additional information.
