Rev 10.0/6-12

10

P1-AC: #35110

T

O

L

IFT AND

M

OVE THE

L

OAD

Positioning the Lift Bar

WARNING: Lift bar must be oriented vertically to lift

load.

Never lift the load from a flat position with the lift bar latched parallel

to the load. Always disengage the tilt latch (see T

O

T

ILT THE

L

OAD

to

follow) and raise the lift bar to a vertical orientation before attempting to lift.

Load Capacity and the Warning Light

A lifter's Load Capacity is rated at a vacuum level of 16" Hg [-54 kPa] (see SPECIFICATIONS).

After the lifter has attained this level, the low vacuum warning light turns off, to indicate that the
lifter is ready to lift the maximum load weight.

WARNING: Never attempt to lift load while red warning light is illuminated.

Do not attempt to lift the load while the warning light is illuminated; such an attempt could result

in a load release and possible injury to the operator.

Monitoring Vacuum Indicators

The low vacuum warning light and the vacuum gauge must remain completely visible to the

operator, so that they can be monitored throughout the entire lift.

WARNING: Vacuum indicators must be visible to operator throughout entire lift.

The lifter’s vacuum pump runs continuously to maintain sufficient vacuum for lifting the

maximum load weight. If the vacuum system experiences leakage while the lifter is attached to
the load, the warning light turns on, to signal the reduction in vacuum to the operator.
If the low vacuum warning light turns on while you are lifting a load, make sure the vacuum

gauge shows a vacuum level of 16" Hg [-54 kPa] or higher. If not, move away and stay clear of
the load until it can be lowered to the ground or a stable support.

WARNING: Stay clear of any suspended load while vacuum level is lower than

16" Hg [-54 kPa].

Discontinue lifter use until the cause of the vacuum loss can be determined. If the vacuum level

remains lower than 16" Hg [-54 kPa] when the lifter is attached to clean, smooth, nonporous
materials, the leakage is likely to be in the vacuum system. In this event, perform the V

ACUUM

T

EST

(see MAINTENANCE) and inspect the vacuum pads for damage (see MAINTENANCE: V

ACUUM

P

AD

M

AINTENANCE

: Inspection). If the vacuum loss cannot be remedied immediately, perform

inspection and maintenance as needed to identify and correct any deficiency before resuming
normal operation of the lifter.

Controlling the Lifter and Load

When vacuum indicators show that the lifter is ready, use the hoisting equipment to raise the

lifter and load as needed to clear any obstacles in their path. Use the control handles to keep the
lifter and load in the desired orientation while they are suspended from the crane. Once
sufficient clearance is established, the load can be rotated or tilted as desired (see T

O

R

OTATE THE

L

OAD

E

DGEWISE

or T

O

T

ILT THE

L

OAD

to follow).
