4. Dimensions of the ACSAR
4. DIMENSIONS OF THE ACSAR
4.1 ACSAR
Outside dimensions
434 mm
17.09 Inches
1
7
7
m
m
6
.9
7
I
n
ch
e
s
456 mm
17.95 Inches
1
7
4
m
m
6
.8
5
In
ch
e
s
416 mm
16.38 Inches
Image 4-1
Outside dimensions
Rack specification
The ACSAR fits into a 19” rack (w) x 4u (h) x 400 (d) mm with input modules.
R5976519 ACSAR 12122002
11
