About your printer, Printer overview, About your printer –2 – Brother HL-1070 User Manual
Page 15: Printer overview –2
USER’S GUIDE
1–2
ABOUT YOUR PRINTER
Printer Overview
Fig. 1-1 Front View
ON
1 2 3 4 5 6 7 8
Fig. 1-2 Rear View
Optional Interface Port
( Serial Interface
Board RS100M)
Multi-Purpose
Sheet Feeder 1
Control Panel
Output Tray
Extension
Support Wire
Paper Support
Paper Guide
Manual Feed Slot
Top Cover
Power Cord
Parallel Interface Port
Power Switch
Multi-Purpose
Sheet Feeder 2
Paper Support
DIP switch
Slide switch
Paper Stopper
Universal
Interface Port
