26 Setup
AUXiliary/COMMunications Menu (Sess 2 - AUX)
EXEC1 GLOBAL COMM1 AUX/COMM2 KEYBOARD1 SCREEN1 VISUAL1 MODE1 TAB1 FUNCT1 BELL
Mode Block H-Blk FDX/Line HDX/Echo
Baud Rate 19200 9600 4800 2400 2000 1800
1200 600 300 150 134.5 110
Parity Odd Odd Even Space Mark
Parity Check Yes No
Data/Stop Bits 7/1 8/1 7/2 8/2
Xon/Xoff None DTR DC1/DC3 Both
Aux Echo Yes No
Pace 00
Terminator US/CR CRLF/ETX
XPC Off On
ENTER:menu ↑ ↓ :line ← → SPACE:select S-SETUP:exit CTL-SETUP:SES#1
Mode [Block, H-Blk, FDX/Line, HDX/Echo]
Four selections are available for defining communication protocol.
Baud Rate [19200, 9600, 4800, 2400, 2000, 1800]
A wide range of baud rates are available to match the data rate for your printer/host.
Parity [Odd, Even, Space, Mark]
Four selections are available to meet the requirements of your printer/host.
Parity Check [Yes, No]
When Yes is selected, an asterisk (*) symbol will be displayed on your screen at any
character position where an error in parity is detected by the terminal on incoming
data.
Data/Stop Bits [ 7/1 , 8/1, 7/2, 8/2]
Select 7 or 8 bit character operation with either 1 or 2 stop bits appended at the end of
a character.
Xon/Xoff [None, DTR, DC1/DC3, Both]
Select DTR, DC1/DC3 or both for data flow control for received character text. Flow
control must be used when using smooth scroll.
