24 Setup
ENTER:menu
↑
↓
:line
←
→
SPACE:select
S-SETUP:exit
CTL-SETUP:SES#1
Screen Timeout [Yes No]
Causes the screen to dim after 15 minutes of inactivity until the first character is
received from the host computer or
keyboard
. While the screen is dim, the
LOCK
key
LED will flash on and off.
CTRL
or
SHIFT
will reactivate the display without
disturbing the displayed data.
Fore/Back
[Blk/Wht, Wht/Blk, Blk/Hlfint, Hlfint/Blk]
Choose to display foreground (Fore) and background (Back) as black/white,
white/black, black/half intensity, or half intensity/black.
Scroll
[SM 8, SM 4, SM 2, SM 1, Jump]
Select your screen to jump or smooth scroll. Four rates of smooth scroll are available,
SM1 representing the slowest, SM8 representing the fastest.
In 44/split mode with smooth scroll enabled, the terminal will default to jump
scroll.
Lines/Sessions [26/1, 26/2, 44/1, 44/Split]
Select the total number of lines displayed and the session to be enabled. The number
of data lines in the scrolling region is selected in the SCREEN menu. Entering or
exiting 44/1 will erase the screen(s). For information on dual session operation refer
to Section 6: Multi host/Split Screen.
Printer Use
[SES1/SER, SES1/PAR, SES2/PAR, None]
Select session 1 serial or parallel printer, session 2 parallel, or no printer. If dual host is
selected SES1/SER is not available. If single host is selected, SES2/PAR is not
available.
Overscan Borders
[Yes,
No
] choose whether the overscan borders are active. The
borders extend video from one edge of the screen to the next.
To see the borders, select Blk/Wht or Blk/Hlfint in the Fore/Back parameter.
Refresh Rate
[60 Hz,
71 Hz
, 82 Hz, 100 Hz] select the rate (number of times per
second) at which the image on your terminal’s display is updated. This selection is
only applicable to 26 line display mode.
COMMunications Menu (Sess 1 - EIA)
EXEC1
GLOBAL
COMM1
AUX/COMM2
KEYBOARD1 SCREEN1 VISUAL1 MODE1 TAB1 FUNCT1 BELL
Mode
Block
H-Blk
FDX/Line
HDX/Echo
Baud Rate
38400
19200
9600
4800
2400
2000
1800
1200
600
300
150
110
Parity
None
Odd
Even
Parity Check
Yes
No
Data Bits
7
8
Stop Bits
1
2
Xon/Xoff
None
DTR
DC1/DC3
Both
Pace
00
Terminator
US/CR
CRLF/ETX
XPC
Off
On
