Table 12 – PHYSICAL DATA
(HEATING)
7.5 -- 12.5 TONS
580J*08
580J*09
580J*12
580J*14
Gas Connection
# of Gas Valves
1
1
1
1
Nat. gas supply line press (in. w.g.)/(PSIG)
4 ---13 / 0.18 --- 0.47
4 ---13 / 0.18 --- 0.47
4 ---13 / 0.18 --- 0.47
4 ---13 / 0.18 --- 0.47
Propane supply line press (in. w.g.)/(PSIG)
11 ---13 / 0.40 --- 0.47
11 ---13 / 0.40 --- 0.47
11 ---13 / 0.40 --- 0.47
11 ---13 / 0.40 --- 0.47
Heat Anticipator Setting (Amps)
1st stage
0.14
0.14
0.14
0.14
2nd stage
0.14
0.14
0.14
0.14
Natural Gas, Propane Heat
# of stages / # of burners (total)
1 / 3
1 / 3
2 / 4
2 / 4
LO
W
Connection size
1/2---in NPT
1/2---in NPT
3/4---in NPT
3/4---in NPT
Rollout switch opens / closes
195 / 115
195 / 115
195 / 115
195 / 115
Temperature rise range (F)
20 --- 50
20 --- 50
25 --- 65
25 --- 65
# of stages / # of burners (total)
2 / 4
2 / 4
2 / 5
2 / 5
MED
Connection size
3/4---in NPT
3/4---in NPT
3/4---in NPT
3/4---in NPT
Rollout switch opens / closes
195 / 115
195 / 115
195 / 115
195 / 115
Temperature rise range (F)
35 --- 65
30 --- 65
30 --- 65
25 --- 65
# of stages / # of burners (total)
2 / 5
2 / 5
2 / 5
2 / 5
HI
G
H
Connection size
3/4---in NPT
3/4---in NPT
3/4---in NPT
3/4---in NPT
Rollout switch opens / closes
195 / 115
195 / 115
195 / 115
195 / 115
Temperature rise range (F)
45 --- 75
40 --- 75
35 --- 70
35 --- 70
