Table 11 – PHYSICAL DATA
(COOLING)
10 -- 12.5 TONS
580J*12A
580J*12D
580J*14D
Refrigeration System
# Circuits / # Comp. / Type
1 / 1 / Scroll
2 / 2 / Scroll
2 / 2 / Scroll
RTPF models R---410a charge A/B (lbs --- oz)
20 --- 0
10 --- 5 / 10 --- 3
11 --- 0 / 11 --- 6
Perfect Humidity R---410a charge A/B (lbs --- oz)
---
16 --- 10 / 16 --- 0
17 --- 10 / 18 --- 3
Metering device
Acutrol
Acutrol
Acutrol
Novation R---410a charge A/B (lbs --- oz)
---
6 --- 0 / 6 --- 0
7 --- 6 / 8 --- 0
High---press. Trip / Reset (psig)
630 / 505
630 / 505
630 / 505
Low---press. Trip / Reset (psig)
54 / 117
54 / 117
54 / 117
Compressor Capacity Staging (%)
100%
50% / 100%
50% / 100%
Evap. Coil
Material (Tube/Fin)
Cu / Al
Cu / Al
Cu / Al
Coil type
3/8---in RTPF
3/8---in RTPF
3/8---in RTPF
Rows / FPI
4 / 15
4 / 15
4 / 15
Total Face Area (ft
2
)
11.1
11.1
11.1
Condensate drain conn. size
3/4---in
3/4---in
3/4---in
Evap. fan and motor
Sta
nd
ar
d
Sta
tic
3p
ha
se
Motor Qty / Drive type
1 / Belt
1 / Belt
1 / Belt
Max BHP
2.4
2.4
2.9
RPM range
591---838
591---838
652---843
Motor frame size
56
56
56
Fan Qty / Type
1 / Centrifugal
1 / Centrifugal
1 / Centrifugal
Fan Diameter (in)
15 x 15
15 x 15
15 x 15
Me
di
um
Sta
tic
3p
ha
se
Motor Qty / Drive type
1 / Belt
1 / Belt
1 / Belt
Max BHP
3.7
3.7
3.7
RPM range
838---1084
838---1084
838---1084
Motor frame size
56
56
56
Fan Qty / Type
1 / Centrifugal
1 / Centrifugal
1 / Centrifugal
Fan Diameter (in)
15 x 15
15 x 15
15 x 15
Hi
gh
S
tat
ic
3p
ha
se
Motor Qty / Drive type
1 / Belt
1 / Belt
1 / Belt
Max BHP
4.7
4.7
4.7
RPM range
1022---1240
1022---1240
1022---1240
Motor frame size
145TY
145TY
145TY
Fan Qty / Type
1 / Centrifugal
1 / Centrifugal
1 / Centrifugal
Fan Diameter (in)
15 x 15
15 x 15
15 x 15
RTPF Cond. Coil
Material (Tube/Fin)
Cu / Al
Cu / Al
Cu / Al
Coil type
3/8---in RTPF
3/8---in RTPF
3/8---in RTPF
Rows / FPI
2 / 17
2 / 17
3 / 17
Total face area (ft2)
25.1
25.1
25.1
Perfect Humidity Cond. Coil
Material (Tube/Fin)
---
Cu / Al
Cu / Al
Coil type
---
3/8---in RTPF
3/8---in RTPF
Rows / FPI
---
2 / 17
2 / 17
Total Face Area (ft
2
))
---
8.4
8.4
Novation Cond. Coil
Material (Tube/Fin)
---
Al / Al
Al / Al
Coil type
---
Novation
Novation
Rows / FPI
---
1 / 20
2 / 20
Total Face Area (ft
2
))
---
25.1
25.1
Cond. fan / motor
Qty / Motor drive type
2 / Direct
2 / Direct
1 / Direct
Motor HP / RPM
1/4 / 1100
1/4 / 1100
1 / 1175
Fan diameter (in)
22
22
30
Filters
RA Filter # / size (in)
4 / 20 x 20 x 2
4 / 20 x 20 x 2
4 / 20 x 20 x 2
OA inlet screen # / size (in)
1 / 20 x 24 x 1
1 / 20 x 24 x 1
1 / 20 x 24 x 1
NOTE: Perfect Humidity is not available with Novation condenser coil models or single stage RTPF 08---12 models.
