4. FIXING UNIT
REF.NO.
CODE
Q'TY
DESCRIPTION
REMARK
1
LJ4164001
1 FIXING UNIT, 115V (SP)
1
LJ4168001
1 FIXING UNIT, 230V (SP)
1
LJ4718001
1 FIXING UNIT, 230V LEG (SP)
1-1
UL8902001
1 THERMISTOR ASSY
1-2
087311215
1 TAPTITE, CUP B M3X12
1-3
LJ4169001
1 HEAT ROLLER 25 (SP)
1-3
LJ4719001
1 HEAT ROLLER 25 LEG (SP)
1-4
UL8908001
2 HR BEARING 25
1-5
LJ4160001
1 HALOGEN LAMP, 115V (SP)
1-5
LJ4163001
1 HALOGEN LAMP, 230V (SP)
1-6
UL8929001
8 EJECT PINCH ROLLER
1-7
LJ4431001
8 PINCH SPRING
1-8
LJ4407001
2 CLEANER ROLLER ASSY
1-9
LJ4409001
2 CLEANER SPRING
1-10
087312015
2 TAPTITE, CUP B M3X20
1-11
Z07200001
1 TAPTITE, PAN B M3X10
1-12
LJ4845001
4 PICK OFF FINGER (SP)
1-13
LJ4853001
1 PRESSURE ROLLER 20 (SP)
1-13
LJ4852001
1 PRESSURE ROLLER 20 LE (SP)
1-14
UL8920001
1 PAPER EJECT ACTUATOR
1-15
UL8921001
1 EJECT ACTUATOR SPRING
1-16 UL8914001 1 IDLE GEAR 13
2
087320815
1 TAPTITE, CUP S M3X8
3
LJ4740001
2 SHOULDER SCREW
MODEL HL-1030/1240/1250/1270/1270N 84U-Z04/Z01/Z02/Z05/Z03-050/051
T/I NO. PR99179, PR99186, PR2000029, PR2000057, PR2000157
- 5 -
