English
WP
T
Supporting
Stud
Supporting
Stud
Wall
Figure 7
When mounting to a wood stud
When you have prepared the holes for mounting the Wall Plate (WP), place the plate
over the holes and screw in the Lag Bolts (T), as shown in Figure 7. Leave some “wiggle”
room so that you can make any fine adjustments, if necessary. After making sure the wall
mount is level, tighten all of the lag bolts completely.
Tighten the Lag Bolts (T) so that the Wall Plate (WP) is firmly attached to the
wall, but don’t over-tighten! The lag bolts and/or the supporting surface can
become damaged, which greatly reduces their holding ability. Final tightening of
the bolts should always be done by hand, with a Phillips-head screwdriver or
ratchet wrench.
