10. Disengage the Winch Clutch (C).
Spool out enough line to anchor the
Winch Cable Spring Shackle (S) to a
structural point on the derrick.
11. Anchor the Winch Cable Spring
Shackle (S) to a structural point on
the derrick. Make sure there is
enough slack in the line to enable the
HawkJaw to move onto the drill pipe
connection.
12. Engage the Winch Clutch (C).
13. Use Winch Off (WOff) to pull the
HawkJaw 3' to 5' ft. away from the
wellbore. This allows the drill pipe
stands to swing straight from pick-
up to stabbing.
Winch Hook-Up Winch Hook-Up
16 Installation
