Memory Card Reader only for Hi-MD Walkman

MCMD-R1 Operating Instruction Card

For more details, refer to Operating Instructions.

To USB jack

The USB cable supplied with the
Hi-MD Walkman

COPY button

To Hi-MD
connector

Access lamp

CHECK
button

Compact flash slot

Compact flash

5-in-1 slot

• All kinds of Memory

Stick

• All kinds of SD cards
• xD-Picture Card
• Smart Media
• Multimedia Card

Insert a memory card
with the front side
upward.

Insert a memory card
with the front side
downward.

2004 Sony Corporation Printed in Japan

Copying the data from a memory card
to a disc in Hi-MD mode

Insert four size-AAA alkaline dry batteries in
the memory card reader.

1

Insert a battery and a disc in Hi-MD mode
(1GB Hi-MD disc or 60/74/80- minute
standard disc) with a sufficient free space in
the Hi-MD Walkman.

2

Connect the memory card reader to the
Hi-MD Walkman.

3

Insert a memory card in the slot.

4

Press the COPY button.
The memory card reader is turned on to start
copying (the access lamp flashes in green).
When copying is complete, the access lamp
stays lit in green. The memory card reader is
automatically turend off about 10 seconds after
completion of copying.

5

After turned off the memory card reader,
press the CHECK button to check the result
according to access lamp indication.
When copying was complete, the access lamp
stays lit in green (refer to the label on the
bottom of the memory card reader).
