Vi-K2/Vi-K3 Universal
Keyboard
Vi-K2 Universal Keyboard User Manual
92
24 Protocol 19 – Vista (PelcoD)
24.1 Connections
Rx-
Rx+
Domes-1 or Domes-2
VX10
5
4
2
1
7
8
3
6
Vi-K2 Keyboard
24.2 Settings
24.2.1 Switch
Settings
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
ON
SW1
SW2
SW3
on
on
1
Notes
• Dome Camera numbers are equivalent to Vi-K2/Vi-K3 Keyboard camera numbers.
• This protocol uses a data rate of 2400 baud
SW1 = Camera number
E.g.
10000000 = Camera 1
11010000 = Camera 11
