KH1508 / KH1516 User Manual
24
OSD Functions
OSD functions are used to configure and control the OSD. For example,
rapidly switching to any port; scanning only selected ports; limiting the list of
ports you wish to view; designating a port as a Quick View Port; managing port
names; or making OSD setting adjustments.
To access an OSD function:
1. Press a Function Key on the keyboard.
2. In the Submenus that appear, make your choice by moving the Highlight
Bar to it, then pressing [Enter].
3. Press [Esc] to return to the previous menu level.
F1 GOTO
Pressing [F1] activates the GOTO function. GOTO allows you to switch
directly to a port either by keying in the port's Name, or its Port ID.
Š To use the Name method, key in 1; key in the port's Name; then press
[Enter].
Š To use the Port ID method, key in 2; key in the Port ID; then press
[Enter].
Note: You can key in a partial Name or Port ID. In that case, the screen will
show all the computers that the User has View rights to (see SET
ACCESSIBLE PORTS, page 30), that match the Name or Port ID
pattern, regardless of the current List settings (see F2 LIST, page 25, for
details).
To return to the OSD Main Screen without making a choice, press [Esc].
