Chapter 1. Introduction
7
No.
Compo-
nent
Description
1
Port
Selection
Switches
Press a switch to give the KVM focus to the computer attached
to its corresponding port.
Simultaneously pressing Buttons 1 and 2 for 3 seconds
performs a Keyboard and Mouse Reset.
Simultaneously pressing Buttons 7 and 8 starts Auto Scan Mode.
2
Port LEDs
The Port LEDs are built into the Port Selection Switches. The
upper ones are the On Line LEDs; the lower ones are the
Selected Port LEDs:
An On Line LED lights GREEN to indicate that the computer
attached to its corresponding port is up and running. A flashing
LED indicates that the Port is being used for cascading to
another switch.
A Selected LED lights ORANGE to indicate that the computer
attached to its corresponding port is the one that has the KVM
focus. The LED is steady under normal conditions, but flashes
when its port is accessed under Auto Scan Mode.
3
Reset
Switch
Pressing this switch in performs a system reset.
Note: The switch is recessed and must be pushed with a thin
object - such as the end of a paper clip, or a ballpoint pen.
4
Firmware
Upgrade
Recovery
Switch
During normal operation and while performing a firmware
upgrade, this switch should be in the NORMAL position. If a
firmware upgrade operation does not complete successfully, this
switch is used to perform a firmware upgrade recovery.
See Firmware Upgrade Recovery, page 48 for details.
5
Firmware
Upgrade
Port
The Firmware Upgrade Cable that transfers the firmware upgrade
data from the administrator's computer to the
KH1508 /
KH1516
(see page 43), plugs into this RJ-11 connector.
6
Power LED
Lights to indicate that the
KH1508 / KH1516
is powered up and
ready to operate.
7
Station ID
LED
The
KH1508 / KH1516
's Station ID is displayed here. If this is a
Single Station installation (see page 12), or the First Station on a
Daisy Chained installation (see page 15), the
KH1508 /
KH1516
has a Station ID of 01.
On a Daisy Chained installation, the
KH1508 / KH1516
auto-
senses its position and displays the Station ID that corresponds to its
place in the chain. (see Port ID Numbering, page 19, for details).
