projection is defined in the local coordinate system
used, coordinates may be either Easting (2nd line),
Northing (3rd line), Height (4th line), or Latitude
(2nd line), Longitude (3rd line) and Ellipsoidal
Elevation (4th line).
Devices Devices are always listed in this order: radio (if any), modem
and WiFi. See screen examples and descriptions below. If one
of these screens is not shown, that means the corresponding
device is absent (radio only) or off.
• Radio:
Rover screen example: – First line: Receiver port that the radio is connected to
(A= external radio; D= internal radio) followed by the
radio function (“Rx” for receiver, “Tx” for transmitter),
the name of the radio model and its current power
status (ON or OFF).
– Second line: Channel number used and its
corresponding frequency, in MHz.
– Third line: Protocol used and transmission speed
(baud rate).
– Fourth line:
Base screen example For a rover, current reception sensitivity (low, medium
or high), followed by “FEC” (Forward Error Correction)
and “SCR” (Scrambling) if these two functions are
enabled, followed by the type of modulation used.
For a base, radiated power (500 mW, 1 W or 2 W),
followed by “FEC” (Forward Error Correction) and
“SCR” (Scrambling) if these two functions are
enabled, followed by the type of modulation used.
• Modem:
– First line: Current modem status (OFF, ONLINE,
READY, DIALING or ON)
– Second line: Identification of the service provider (ISP)
– Third line: Network type (2G or 3G) and measured
signal level (in 20% steps; 100%: +43 dBm)
– Fourth line: Connection type (NTRIP or Direct IP)
followed by mount point name (in NTRIP), or server
address, i.e. host name or IP address (in Direct IP).
• WiFi:
– First line: Current WiFi status (CONNECTED, ON, OFF)
– Second line: Identification of the WiFi server
– 3rd line: Signal level (in 20% steps; 100%: +43 dBm)
– Fourth line: Same as Modem’s fourth line above.
