18
Area
Icon or Data
Reported
Meaning
[7]
Where located, the right arrow indicates which bat-
tery is currently used.
[8]
Batteries:
/ {percent}
A battery has been inserted in the compartment and
the energy left in the battery is represented both
visually and as a percentage. These two indications
are shown successively (percentage appears for
1 second every 5 seconds).
The battery is missing (the battery compartment is
empty).
[9]
The receiver is powered from the AC/DC power
block, not by one of its batteries.
[8]
+
[9]
/ {percent}
(Battery B only) Case where the receiver is powered
from the AC/DC power block and battery B is present
with a certain percentage of remaining power.
[10]
Modem:
(Blank) Modem turned off.
or
Modem turned on:
• Blinking: Not initialized yet
• Static: Initialized and ready for a connection
The vertical bars indicate the signal strength at the
modem antenna input. The higher the number of
bars the better.
The antenna symbol shown in the upper left corner
stands for “2G”. If the modem detects a 3G network,
“3G” is displayed instead.
When the signal strength is very weak, four dots
appear at the bottom of the icon, instead of vertical
bars.
Modem on line.
[11]
WiFi:
(Blank) WiFi turned off.
WiFi connection active (1 to 3 waves depending on
signal level).(1 wave: no signal yet)
Data being transmitted over Wifi (2 to 3 waves).
[12]
SD Card, Bluetooth, USB:
SD card present
Bluetooth connection active
USB connection active
/ /
Any combination of the three icons is possible. Icons
appear in succession every 1 second.
(Blank)
No SD card present, No Bluetooth or USB connec-
tion active.
