ePhoto CL30 User’s Guide 25
Changing Advanced Settings
External Flash
Your ePhoto CL30 can be used with any external flash equipped
with a white light slave sensor. Whenever a picture is taken, the
external flash is triggered by a low-power burst of light from the
camera’s built-in flash.
The external flash settings are:
◗ Small 1/200
◗ Large 1/200
◗ Small 1/100
◗ Large 1/100
◗ Off
The sizes refer to the aperture size, and the times (in sec-
onds) indicate the shutter speed.
To use an external flash:
1. Select Ext. flash in the ADVANCED menu.
2. Select a large or small aperture based on these ranges:
Large: f/2.8 – 3.5, wide – telephoto
Small: f/8.0 – 9.1, wide – telephoto
Icon Setting Selected
External flash
