<4. Installation>
4-2
IM 01C27B01-01EN
Transmitter
mounting bolt
Spacer
U-bolt nut
Mounting bracket
50 mm (2-inch)
pipe
U-bolt
F0402.ai
Spacer
U-bolt nut
Mounting bracket
50 mm (2-inch)
pipe
U-bolt
Transmitter
mounting bolt
Horizontal pipe mounting
Vertical pipe mounting
Figure 4.2 Transmitter Mounting (Horizontal
Impulse Piping Type)
F0403.ai
Transmitter
mounting bolt
Transmitter mounting bolt
Mounting bracket
Mounting bracket
U-bolt nut
U-bolt nut
U-bolt
U-bolt
50 mm (2-inch) pipe
50 mm (2-inch) pipe
Vertical pipe mounting (Process connector downside)
Vertical pipe mounting (Process connector upside)
Figure 4.3 Transmitter Mounting (Vertical Impulse
Piping Type)
