<11. General Specifications>
11-16
IM 01C27B01-01EN
230 (9.06)
319 *6 (12.56)
105 (4.13)
257 *6 (10.12)
72 (2.83)
46
(1.81)
102 (4.02)
52
(2.05)
140 (5.51)
176
*4
(6.93)
234 (9.21)
 Vertical impulse piping type (Installation code 7 and Amplifier housing code 7)
*1
 Horizontal impulse piping type (Installation code 9 and Amplifier housing code 7)
*1
97 (3.82)
64
(2.52)
148 (5.83)
*3
191 (7.52)
39
(1.54) 24
(0.94)
Ø
110 (4.33)
2-inch pipe
(O. D. 60 mm)
Process connector
(Optional)
Process
Connection
Integral indicator
Mounting bracket
(L-type, optional)
High
pressure
side
Low
pressure
side
27
(1.06)
Open to atmosphere
Ø10 (0.39)
Vent/Drain plugs
Ground terminal
Zero adjustment
*1: When installation code 3 and 8 is selected, high and low pressure side on above figure are reversed.
(i.e. High pressure side is on the right side.)
*2: When option code K1, K2, K5, or K6 is selected, add 15 mm (0.59 inch) to the value in the figure.
*3: Applicable for EJX430B.
*4: When amplifier housing code 8 is selected, the value is 234 mm (9.21 inch). When amplifier housing code 9 is
selected, the value is 114 mm (4.49 inch). In both cases, the figures are shown as A or B accordingly.
*5: When amplifier housing code 8 is selected, the value is 374 mm (14.72 inch). When amplifier housing code 9
is selected, the value is 254 mm (10.00 inch). In both cases, the figures are shown as A or B accordingly.
*6: When amplifier housing code 8 or 9 is selected, subtract 1 mm (0.04 inch) from the value.
*7: When amplifier housing code 8 or 9 is selected, add 1 mm (0.04 inch) to the value.
F07.ai
Unit: mm (approx. inch)
Wetted parts material code: H, M, T, A, B, and D *3
Wetted parts material code: H, M, T, A, B, and D *3
A B
64
(2.52)
191 (7.52)
39
(1.54)
24
(0.94)
46
(1.81)
47
(1.85)
Process connection
Process connector
(Optional)
Mounting bracket
(Flat-type, optional)
Integral indicator
45 *7
(1.77)
124 (4.88)
196 (7.72)
316
*5
(12.44)
230 (9.06)
140
(5.51)
72
(2.83)
127
(5.00)
158
(6.22)
Ø
110 (4.33)
Drain plug
Vent plug
Ground terminal
Zero adjustment
High
pressure
side
Low
pressure
side
2-inch pipe
(O. D. 60 mm)
27
(1.06)
64 *2
(2.52)
Open to
atmosphere
Ø5 (0.20)
For electrical
connection code
5, 9, A, and D
6
(0.24)
76
(2.99)
For electrical
connection code
5, 9, A, and D
6
(0.24)
76
(2.99)
