LCD-KIT
Page 49
Level 0
Level 1
Value
H. Position
0 to 100
V. Position
0 to 100
OSD Time Out
0 to 60 sec
OSD Position
1 to 5
OSD Menu
Factory Reset
Select
Digital
Signal Menu
Analog
Select
Table 6-1: OSD Menus
6.2 Using the OSD
OSD menu options are described below.
6.2.1 Main Display Features
Main display features are shown in Figure 6-3.
Figure 6-3: Main Display Features
Brightness
:
