Figure 3-5: Reset CMOS Jumper Location

3.4.2 AT/ATX Power Selection

Jumper Label:

JP10

Jumper Type:

2-pin header

Jumper Settings:

See Table 3-2

Jumper Location:

See Figure 3-6

This jumper sets the power mode to AT or ATX.

Pin

Description

Closed

ATX (Default)

Open

AT

Table 3-2: AT/ATX Power Selection
