SAILORPC-12A Panel PC
Page 14
3.1 Tighten the Pressure Release Screw
WARNING:
Fasten the pressure release screw on the back panel before use. The
pressure release screw is loosened before shipping, but must be
tightened before use to ensure the system is completely watertight.
Tighten the screw shown below to 7 kg-cm (6 lb-ft/0.68 Nm).
Figure 3-1: Pressure Release Screw
3.2 Hard Drive Installation
This section outlines the installation of the hard drive in the SAILORPC-12A. To install the
hard drive, please follow the steps below:
Step 1: Remove the plastic back cover.
Step 2: Unfasten the screws. Lift the cover to remove (Figure 3-2).
