UPC-V312-D525 Panel PC

Page 30

Figure 3-12: Chassis Support Screws

NOTE:

In the diagram below the bracket is already installed on the wall.

Step 9:

Secure the panel PC by fastening the retention screw of the wall-mounting

bracket. (Figure 3-13).
