UPC-V312-D525 Panel PC
Page 24
Step 2: Pry the cover up from the upper right corner using a flat-head screwdriver.
Continue to pry gently along the gap of the cover until the cover can be
removed.
Figure 3-4: Pry along the Internal USB Port Cover
Step 3: Remove the internal USB port cover and locate the internal USB port. See
556
Figure 3-5 .
Figure 3-5: Internal USB Port Location
