Technical Data
Please note: Due to technical improvements all specifications are subject to change!
25
Camera / Technology (Signal format)
Pictures per second (as picked up by the camera)
Native (effective Pixels of camera sensor)
Native pixels of image processing
Pixels processed per second
(=effective pixels x frames per sec.)
Color reproduction / precision
Output signals 4:3 and 5:4
Output signals 16:9 and 16:10
WolfVision image processing engine "YSOP1"
Resolution (measured)
Vertical image-frequency
(depending on selected output mode)
Iris (Brightness adjustment)
White balance adjustment
Focus
Center Lasermarker for easy object positioning
On-screen menu and on-screen help
Upgradeable firmware
Lens / Zoom
Lens type
Max. object height on working surface level
Max. pick-up area on working surface level
Min. pick-up area on working surface level
Min. pick-up area on working surface level with
digital zoom
Depth of focus on small object (42 x 33 mm)
Depth of focus on large object (360 x 270 mm)
vSolution Link Software (USB and LAN, for
controlling, image and video capturing and
firmware updates)
Reflection free area on working surface level
User programmable presets
Special working surface for transparencies
Bottom light
Image memory
Seamless cross fading
Built-in digital scaler
Alternative Image display
HDMI output / DVI and DisplayPort output
RGB output
Audio
USB standard / port
Ethernet (LAN)
WLAN (WiFi)
Web Interface
Streaming
Recording
Advanced controlling with professional protocol
Dimensions (L x W x H)
Weight
Infrared remote control
External IR-sensor
Tripod Mount
U-shaped Mounting Clip
Voltage input
Supplied Power Pack
Power consumption
Operating Temperature / Relative Humidity
Warranty
Made in
CMOS 1/3" Progressive Scan
30 frames per second
1920x1080 (=2,073,600), ratio 16:9
1920x1080 (=2,073,600), ratio 16:9
62,208,000, ratio 16:9
very good colors / sRGB color precision
SVGA (800x600), XGA (1024x768), SXGA (1280x1024), UXGA (1600x1200)
720p HD (1280x720), WXGA (1280x800), 1080p HD (1920x1080),
WUXGA (1920x1200)
yes
980 lines
Progressive Scan: 30Hz, 50Hz and 60Hz (switchable)
automatic and manual
automatic and manual
automatic and manual
yes
yes
yes, via USB, Ethernet/LAN and USB-stick
zoom lens 56x zoom (14x optical + 4x digital)
wide angle, f= 4.7 - 66mm
depending on installation height
depending on installation height
depending on installation height
depending on installation height
depending on distance to object and intensity of illumination
depending on distance to object and intensity of illumination
included (for 32- and 64-bit Windows and Macintosh)
TWAIN / WIA compatible
depending on installation of room light
3
optional
optional
internal memory 8GB micro SD + unlimited memory via USB stick
yes
yes
negative image / negative-blue image / black and white image
yes, inclusive audio support / yes, with optional adapter
yes
yes, HDMI, Line In and Line Out (max. 1V
RMS
@10kOhm)
1x USB 2.0 device port (incl. PTP and UVC) and 2x USB 2.0 host ports
yes, IP-addressable, 10/100 Mbps
n-draft USB dongle optional (BYOD Pack)
yes (IP addressed)
MJPEG, RTP MJPG, H.264 (unicast and multicast)
yes (720p HD, up to 30 frames per second
USB and LAN (WLAN)
127mm x 125mm x 91.5mm (5" x 4.9" x 3.6")
1kg (2.24lbs)
yes (with laserpointer)
optional, with 10m cable
2 tripod mounts (on top and bottom, 1/4-20 UNC)
yes
PoE+ (Power over Ethernet Plus) (IEEE 802.3at standard)
multi range 100-240 V, 21W power consumption
adjustable standby power consumption
5 years
Austria (European Union)
0°C - 40°C (32°F - 104°F) / 40 - 60%rel
