Win-Holt SCASU Series Shelving - Manual (Page 9)

S
HEL
VING
P
AGE
54
800.444.3595 I 516.921.0538 fax I www.winholt.com
Ideal for boxed beef. Constructed of all welded, heavy duty
aluminum.
Maneuvers easily on two 6" x 2" phenolic swivel plate
casters and two 6" x 2" rigid plate casters.
Model
Number
Ordering
Number
Overall Dimensions
Capacity
Approx.
Ship Wt Width Length Height
(in) (mm) (in) (mm) (in) (mm) (lb) (kg) (lb) (kg)
SMC-63 102411 25 635 63 1,600 71 1,803 3,000 1,361 70 32
Caster Information
7311BK 211115 Swivel Plate Caster with 6" Phenolic Wheel & Brake ⎯
746 123481 Rigid Plate Caster with 6" Phenolic Wheel
⎯
7119 122331 6" Phenolic Wheel ⎯
SMC-63
Freight Class: 300
Model
Number
Ordering
Number
Overall Dimensions
# of
Shelves
Space
Between
Shelves
Approx.
Ship Wt. Width Length Height
(in) (mm) (in) (mm) (in) (mm) (in) (mm) (lb) (kg)
Mobile - Tubular Bar Style
ALMCS-36-424 180988 24 610 36 914
60 1,524
4 15 1 /
8 384 70 32
ALMCS-48-320 102171 20 508
48 1,219
3 22 ½ 572
65 29
ALMCS-48-324 102189 24 610 73 33
ALMCS-60-320 186968 20 508
60 1,524
76 34
ALMCS-60-324 132249 24 610 60 1,524 80 36
Mobile - E-Channel
ALMCH-48-220 244486
20 508 48 1,219 60 1,524
2 34 ½ 876 40 18
ALMCH-48-320 244494 3 22 ½ 572 50 23
Caster Information
7311BK 211115 Swivel Plate Caster with 6" Phenolic Wheel & Brake ⎯
746 123481 Rigid Plate Caster with 6" Phenolic Wheel ⎯
7119 122331 6" Phenolic Wheel ⎯
Sani-Mobile Cooler Cart
Heavy Duty
Mobile Cooler Shelving
Sanitary and easy to clean. Constructed of all welded,
heavy duty, sanitary aluminum.
Mobile units roll easily on two rigid and two swivel heavy
duty casters, with 6” x 2” phenolic wheels.
Freight Class: 300
ALMCS
Heavy Duty 6" Casters
Option:
Specify options by adding suffix to Model Numbers listed above.
LC
......................Locking Caster
B
ETTER
H
EAVY
D
UTY U SE
L
IFE
W
ARRANTY
A GAINST R UST
Equipment Guide
B ETTER
H EAVY D UTY U SE
L IFE W ARRANTY
A GAINST R UST
Equipment Guide
