Win-Holt BNQT Series - Manual

T
RANSPORT
& M
OBILE
S
TORA
GE
P
AGE
26
800.444.3595 I 516.921.0538 fax I www.winholt.com
Freight Class: 250
B ETTER
H EAVY D UTY U SE
L
IFE
W
ARRANTY
A GAINST R UST
Equipment Guide
Multipurpose cart designed for storage and
transportation of pots, pans, wire baskets, cups, and
dishes.
The frame is constructed of all welded 1½" x 1½" x
3/16" all welded reinforced aluminum. The shelves are
constructed of heavy duty reinforced aluminum sheet.
Standard configuration is 3 lips flanged up and front lip
down. Other configurations are available upon request.
A wrap around bumper protects walls, associates and
equipment. Welded handle for easy maneuverability.
Maneuvers on two 8" x 2" rigid and two 8" x 2" swivel
polyurethane wheels with double race casters.
Queen Mary Banquet Carts
Aluminum
Multipurpose cart designed for storage and transportation
of pots, pans, wire baskets, cups, and dishes.
304 Stainless Steel
A wrap around bumper protects walls, associates and
equipment. Welded handle for easy maneuverability.
Maneuvers on two 8" x 2" rigid and two 8" x 2" swivel
polyurethane wheels with double race casters.
Model
Number
Order#
Overall Dimensions
# of
Shelves
Shelf
Spacing
Approx.
Ship
Weight
Width Length Height
(in) (mm) (in) (mm) (in) (mm) (in) (mm) (lb) (kg)
BNQT-3 154325
28 711 60 1,524 65 7 /
16
1,662
3 27 686 140 64
BNQT-4 127546 4 17 19 /
32
447 160 73
BNQT-5 112598 5 13½ 343 180 82
Caster Information
73161 123035 Swivel Plate Caster with 8" Mold-on Polyurethane Wheel
⎯
7471 123537 Rigid Plate Caster with 8" Mold-on Polyurethane Wheel ⎯
7116 122294 8" Mold-on Polyurethane Wheel ⎯
Queen Mary Banquet Carts
Stainless Steel
Model
Number
Order#
Overall Dimensions
# of
Shelves
Space
Between
Shelves
Approx.
Ship Wt Width Length Height
(in) (mm) (in) (mm) (in) (mm) (in) (mm) (lb) (kg)
BNQT-3SS 232012
28 711 60 1,524 65 7 /
16 1,662
3 27 686 295 134
BNQT-4SS 168997 4 17 19 /
32 447 340 154
BNQT-5SS 232021 5 13½ 343 385 174
Caster Information
73161 123035 Swivel Plate Caster with 8" Mold-on Polyurethane Wheel ⎯
7471 123537 Rigid Plate Caster with 8" Mold-on Polyurethane Wheel ⎯
7116 122294 8" Mold-on Polyurethane Wheel ⎯
B EST
H EAVY D UTY U SE
L IFE W ARRANTY
A GAINST R UST
Equipment Guide
Ideal for
Food Service
& Industrial
Environments!
In line with our policy to continually improve our
products, Win-Holt reserves the right to change ma-
terials and specifications without notice. Freight Class: 250
