Win-Holt Bulk Movers - Manual

P AGE
89 800.444.3595 I 516.921.0538 fax I www.winholt.com
F
OOD
H
ANDLING
B ETTER
H EAVY D UTY U SE
L IFE W ARRANTY
A GAINST R UST
Equipment Guide
Bulk Movers, 3, 6 & 8 Bushel
Aluminum and Stainless Steel
Ideal for all Departments - Meat, Produce, Fish and Deli!
Food Preparation - Pack out - Storage!
The most useful tool for Backroom Processing!
Use our efficient Department Color Coding System:
Blue for Fish, Red for Meat, White for Produce.
Large removable tub is constructed of sanitary, washable
and steam cleanable polyethylene.
Frame constructed of all-welded, rust proof aluminum or
stainless steel (see bottom of page).
Maneuvers easily on four 5" swivel polyurethane casters.
6 Bushel Unit
30-6-A/BL
BLC-1
Model
Number
Order
Number
Overall Dimensions
Tub
Color
Approx.
Ship Wt
Width Length Height
(in) (mm) (in) (mm) (in) (mm) (lb) (kg)
3 Bushel - 6,840 Cubic Inches (500 lb) Bulk Movers–Aluminum Base
Complete Unit (frame and tub)
BLC-1 101602 19 483 30 762 32 813 White 14 6
Tub only
XT-BLC 101776 19 483 30 762 12 305 White 6 3
6 Bushel - 16,632 Cubic Inches (500 lb ) Bulk Movers–Aluminum Base
Complete Unit (frame and tub)
30-6-A / WH 101477
24 610 33 838 36 914
White
28 13
30-6-A / BL 161111 Blue
30-6-A / GY 153066 Gray
30-6-A / RD 161103 Red
Tub only
TUB-6A-WH 101725
24 610 33 838 21 533
White
12 5
TUB-6A-BL 161146 Blue
TUB-6A-GY 101709 Gray
TUB-6A-RD 101717 Red
8 Bushel - 20,664 Cubic Inches (500 lb) Bulk Movers–Aluminum Base
Complete Unit (frame and tub)
30-8-AL / WH 161120
22 559 38½ 978 32 813
White
39 18 30-8-AL / BL 155942 Blue
30-8-AL / RD 161138 Red
Tub only
TUB-8L-WH 101750
24 610 41 1,041 21 533
White
22 10 TUB-8L-BL 101733 Blue
TUB-8L-RD 101741 Red
Caster Information
757 123684 Swivel Stem Caster with 5" Polyurethane Wheel
7112 122180 5" Polyurethane Wheel
For
Stainless Steel
For 6 and 8 bushel Stainless Steel Bulk Movers change the “A” in the model
number to “S” or the “AL” to “SS”
Option:
PDP-6 (101645) . . . .Drip Pan
8 Bushel Unit
30-8-A/RD
Complete Unit Freight Class:250
Tub Only Freight Class: 70
